| Prime Power | kVA | 450 |
| Prime Power | kW | 360 |
| Standby Power | kVA | 500 |
| Standby Power | kW | 400 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Brand | PERKINS | |
| Model | 2506A-E15TAG1 | |
| Cylinder Configuration | Inline | |
| Number of cylinders | 6 | |
| Cylinder Volume | 15,2 | |
| Cylinder Diameter | 137 | |
| Cylinder Length | 171 | |
| Compression Ratio | 16:01 | |
| Ventilation Type | Turbo-charged – Intercooler | |
| Governor Type | Elektronic/ECM | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 58 |
| Total Oil capacity | lt | 62 |
| Electrical System (DC) | 24 | |
| Speed/Frequency | rpmz | 1500/50 |
| Engine Power | kW | 451 |
| 110% Fuel Consumption at Load | lt | 104 |
| Fuel Consumption at 100% Load | lt | 95lt |
| 75% ESP Fuel Consumption at Load | lt | 72 |
| 50% ESP Fuel Consumption at Load | lt | 50 |
| Exhaust Exhaust Temperature | °C | 550 |
| Exhaust Gas Flow | m3/min | 81 |
| Combustion Air Flow | m3/min | 30,5 |
| Cooling Air Flow | m3/min | 722 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Tek | |
| Number of Poles | 4 | |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1650X3300X2078 |
| Fuel Tank Capacity | mm | 750 |
| Weight | kg | 3546 |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1650X5200X2280 |
| Fuel Tank Capacity | mm | 750 |
| Weight | mm | 4366 |
