| Prime Power | kVA | 650,0 |
| Prime Power | kW | 520,0 |
| Standby | kVA | 715,0 |
| Standby Power | kW | 572,0 |
| Standart Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Rated At Power Factor | Cos Phi | 0,8 |
| Brand | BAUDOUIN | |
| Model | 6M33G715-5 | |
| Cylinder Configuration | In-Line | |
| Number of cylinders | 6 | |
| Cylinder Volume | 19,6 | |
| Cylinder Diameter | 150 | |
| Cylinder Length | 185 | |
| Compression Ratio | 15:01 | |
| Ventilation Type | Turbo-charged – Aftercooler | |
| Governor Type | Electronic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 129 |
| Total Oil capacity | lt | 61 |
| Electrical System (DC) | 24 | |
| Speed/Frequency | rpm | 1500/50 |
| Engine Power | kW | 633 |
| 110% Fuel Consumption at Load | lt | 153,6 |
| Fuel Consumption at 100% Load | lt | 135,1 |
| 75% ESP Fuel Consumption at Load | lt | 99,3 |
| 50% ESP Fuel Consumption at Load | lt | 66,4 |
| Exhaust Exhaust Temperature | °C | 550 |
| Exhaust Gas Flow | m3/min | 121 |
| Combustion Air Flow | m3/min | 44 |
| Cooling Fan Flow | m3/min | 767 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Single | |
| Number of Poles | (V) | 4 |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | % | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 1400X4500X2032 |
| Weight | kg | 5329 |
| Fuel Tank Capacity | lt | 1400 |
Dimensions With Canopy and Weight |
||
| Width x Length x Height | mm | 2200X5600X2450 |
| Weight | kg | 6814 |
| Fuel Tank Capacity | lt | 1400 |
