| Prime Power | kVA | 8,3 |
| Prime Power | kW | 6,64 |
| Standby Power | kVA | 9 |
| Standby Power | kW | 7,2 |
| Standard Voltage | V | 400/231 |
| Revolutions per Minute | r.p.m | 1500 |
| Power Factor | Cos Phi | 0,8 |
| Brand | PERKINS | |
| Model | 403A-11G1 | |
| Cylinder Configuration | Inline | |
| Number of cylinders | 3 | |
| Cylinder Volume | 1,131 | |
| Cylinder Diameter | 77 | |
| Cylinder Length | 81 | |
| Compression Ratio | 23:01 | |
| Ventilation Type | Natural Aspiration | |
| Governor Type | Mechanic | |
| Cooling Type | Water | |
| Cooling Capacity | lt | 5,2 |
| Total Oil capacity | lt | 4,9 |
| Electrical System (DC) | 12 | |
| Speed/Frequency | rpmz | 1500/50 |
| Engine Power | kW | 9,5 |
| 110% Fuel Consumption at Load | lt | 2,9 |
| Fuel Consumption at 100% Load | lt | 2,6 |
| 75% ESP Fuel Consumption at Load | lt | 2 |
| 50% ESP Fuel Consumption at Load | lt | 1,5 |
| Exhaust Exhaust Temperature | °C | 420 |
| Exhaust Gas Flow | m3/min | 1,8 |
| Combustion Air Flow | m3/min | 0,7 |
| Cooling Air Flow | m3/min | 26,4 |
| Phase Number | 3 | |
| Power Factor | 0,8 | |
| Number of Beds | Tek | |
| Number of Poles | 4 | |
| Number of Terminal Ends | 6-12 | |
| Insulation Class | H | |
| Protection Class | IP23 | |
| Warning System | AVR |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 730X1300X922 |
| Fuel Tank Capacity | mm | 100 |
| Weight | kg | 395 |
Dimensions Without Canopy and Weight |
||
| Width x Length x Height | mm | 730X2100X1200 |
| Fuel Tank Capacity | mm | 100 |
| Weight | mm | 551 |
